Diameter: 1/2″, 3/4″, 1″, 1 1/4″, 1 1/2″, 2″, 3″, 4″
The softest on the market, body made of high-strength rigid PVC.
- Tool-free installation.
- Body made of high-strength rigid PVC.
- Gentle turning of the nut.
- Accuracy of the o'ring cavity prevents the o'ring from falling out.
- Threaded and socket presentation.
- Maintains full flow and minimizes pressure drop.
- Threaded with NPT-type thread
- Maximum working pressure:
- 235 psi at 74ºF in threaded joints.
- 150 psi at 74°F in socket joints.
- Threads are in accordance with ANSI B1.20.1.
- Complies with ASTM D2466- Socket standards
- Complies with ASTM D2467- Threaded standards
